Standard equipment:

• Primary voltage up to 24 kV;

• Secondary voltage up to 0.690 kV;

• Insulation class up to 24 kV;

• Connection scheme (from 100 kVA to 3150 kVA): triangle/star with a zero output (others on request);

• Group: Y-Yn-0 or Dyn11 or Dyn5 (others on request);

• Rated frequency 50 Hz;

• Magnetic circuit of high quality electrical textured steel with oriented structure;

• High voltage winding of aluminum flooded with epoxy resin in vacuum;

• Low voltage winding of aluminum and insulation materials impregnated with epoxy resin in vacuum;

• Jumpers for the primary voltage variation;

• LV contact pads;

• Wheels for longitudinal and transverse movement;

• Lifting lugs;

• Ground connection;

• Temperature control probe Pt 100 (3 pcs.) connected to the junction box;

• Temperature control electronic unit;

• Nameplate;

• Protection level: IP 00.
